Electronics Prototyping

Fab

Unadjustednonraw thumb 8c.jpg

A site for prototyping, testing, debugging, and fabricating electronic circuits.

Machines/Equipment

Bantam Tools Desktop Milling Machine

Bantamtools machinefront whitesquare 244553da 73c1 40c0 8cc0 f0f373b30db7 1000x1500.jpg

PCB mill - one-sided and two-sided copper FR1.

Training Required

Hakko Soldering Iron

41p4q888 9l.jpg

General-purpose soldering.

Training Required

DC Power Supply (0-32V, 0-10.2A)


General-purpose power supply. Use in lieu of batteries when prototyping.

Saleae Logic Analyzer

91a8x9hmhzl. sl1500 .jpg

General-purpose debugging. Useful for parsing errors from I2C/SPI communication protocols.

AgIC Silver Ink Circuit System (Epson ET-2720)


For making flexible circuits. Do not solder. Use conductive tape, z-tape, or conductive glue to attach components.

Function Generator


Used for generating waveforms to actuate electronics.

Voltera V-One PCB Printer

V one.png ha

CNC PCB printer for laying down silver ink traces and SMD components.

Training Required
Training Required

Digital Microscope

61wqajqpccl. ac sl1200 .jpg ha

Useful for soldering and debugging SMD electronics.

Tools

Fluke 115 Multimeter

71rivvonyrl. sl1500 .jpg

For electronics debugging.

Wireless Digital Microscope

51eexz2yxml. ac sl1100 .jpg ha

For inspecting soldering joints.

Materials

60/40 Tin Lead Solder


General-purpose soldering.

Training Required

Copper Tape

61tpx ldfql. sl1001 .jpg

Good for quick repairs, conductive pad electrodes, or for paper circuits.

TAP Platinum Silicone

Platinum silicone gal xl.jpg

Great for encapsulated embedded circuits.

Training Required

Self-Adhesive Vinyl Film (24"x30') & Transfer Tape

Sign vinyls fdc 4200 spec  54864.1449615113.1280.1280.png

Great conductive ink screenprinting material.

Buttons, Switches, & Sensors

Buttons 1884444 1280.jpg

For detecting input and sensing environmental variables.

Breadboards & Electronic Components

Arduino 2713093 1280.jpg

For testing, debugging, and exploring circuit designs.

Actuators: Lights, Motors, Speakers

Stepper motor 1317806 1280.jpg

Useful for introducing changes into the environment or as a feedback mechanism.

Batteries, Power Supplies, and Connectors

Battery 1930833 1280.jpg

Supply power to circuits and breadboards with a range of power supplies.

Microcontrollers

Arduino 1050655 1280.jpg

Issue control logic to analog and digital circuits.

Copper Nanopowder

Copper powder 500x500.png ha

Useful for creative conductive materials.

Training Required

Graphite Nanopowder

Graphite powder ca9cfff55d83c1969e4a2e4a0c1adfd1.jpeg ha

Useful for creative conductive materials.

Training Required
